BLINDER 4 EYE 616F
4-Eye Brilliance. High-Performance Matrix.
The Matrix Panel 616F is a high-performance 4-eye blinder and strobe fixture. It utilizes 4x 100W COB (Cool White + Warm White) LEDs paired with an integrated array of 96x 0.2W RGB LEDs, delivering a staggering 8000K color temperature and piercing 4.5° beams.
Encased in a sleek black housing with an efficient fan cooling system, it guarantees reliable performance. It includes diverse built-in color macros, crisp 0-100% dimming, and supports 40 or 44 DMX channels for sophisticated matrix and ring animations.
Technical Parameters
Optics & Light Source
- Main Source: 4x 100W COB Dual White (CW+WW)
- Auxiliary Source: 96pcs 0.2W RGB LEDs
- Color Temperature: 8000K
- Beam Angle: 4.5° tight beam coverage
Dynamic Effects
- Dimming: 0-100% smooth electronic dimming
- Strobe: 0-25Hz high-speed variable strobe
- Brightness: 1500 Lux @ 3m
Control & Programming
- Control Modes: DMX / Auto / Sound / Master-Slave
- DMX Channels: 40 / 44 CH modes
- Interface: Integrated control panel
Electrical & Physical
- Power Consumption: 330W (AC100-240V, 50/60Hz)
- Environment: IP20 rated (Max ambient 45°C)
- Cooling: Fan cooling method
- Connections: 3-Pin XLR in/out, PowerCon in/out
- Dimensions: 370 x 551 x 180 mm | Weight: 6.8 kg
Product Gallery
Technical Resources
Download the complete product package including user manuals, DMX charts, and technical dimensions.
Download All (ZIP)
