STROBE BAR 1200 IP65
Linear Intensity. Weatherproof Mapping.
The Strobe Bar 1200 IP is a robust, meter-long outdoor LED strobe and wash luminaire. It features a colossal matrix of 1152x 0.5W RGBW 4-in-1 LEDs flanked by a dual-temperature strobe core consisting of 192x 1W Cool White and 96x 1W Warm White LEDs. This hybrid configuration delivers sweeping washes, intense blinder effects, and pixel-mapped animations.
Designed with a sleek, horizontal interlocking system, multiple units can be seamlessly joined to create continuous walls of light. It incorporates an electronic frost filter (1-100%) for softening beams, and boasts advanced network capabilities including Art-Net, RDM, and vast DMX channel modes (up to 4657 channels) for ultimate pixel manipulation.
Technical Parameters
Optics & Light Source
- Wash Source: 1152x 0.5W RGBW 4-in-1 LEDs
- Strobe Source: 192x 1W CW (6500K) + 96x 1W WW (3000K)
- Beam Angle: 120° ultra-wide coverage
- Electronic Frost: 1-100% linear variable frost
Dynamic Effects
- Hybrid Modes: Wash, Strobe, Blinder, and Built-in Effects
- Dimming: 0-100% smooth linear dimming
- Strobe: 1-25Hz high-speed variable strobe
Control & Programming
- Protocols: DMX512 / Art-Net / RDM / Auto / Master-Slave
- DMX Channels: 21 / 69 / 99 / 179 / 339 CH
- Art-Net Channels: 49 / 97 / 177 / 337 / 561 / 1201 / 4657 CH
- Interface: LCD display with 4 touch buttons
Electrical & Physical
- Power Consumption: 500W (AC100-240V, 50/60Hz)
- Environment: IP65 Rated (Outdoor waterproof)
- Connections: Waterproof power, 3-pin XLR, and RJ45
- Dimensions: 1000 x 156 x 160 mm | Weight: 11 kg
Product Gallery
Technical Resources
Download the complete product package including user manuals, DMX charts, and technical dimensions.
