CITY COLOR 3240 STROBE IP65
Monumental Wash. Blinding Strobe.
The City Color 3240 Strobe IP65 is a hybrid architectural and stage wash luminaire designed for massive output. It uniquely combines 32 ultra-bright 40W RGBW LEDs with a blinding center array of 144x 5W cool white (7000K) strobe LEDs. This dual-functionality allows lighting designers to bathe entire buildings in rich colors while delivering explosive, high-energy strobe effects.
Built to withstand the harshest outdoor environments, the 3240 features a rugged die-cast aluminum housing with an IP65 waterproof rating. With a massive 1300W power consumption and a perfectly calibrated 40° beam angle, it ensures seamless and even color mixing over vast distances. Advanced DMX mapping capabilities give you complete control over pixel zones and dynamic strobe macros.
Technical Parameters
Optics & Light Source
- Main Wash Source: 32x 40W Quad RGBW LEDs (50,000 hrs lifespan)
- Strobe Source: 144x 5W White LEDs (7000K-7500K)
- Beam Angle: 40° for wide and even architectural coverage
- Dimming: 0-100% smooth linear dimming
Dynamic Effects
- Hybrid Design: Seamless color wash mixed with intense blinding strobe
- Strobe Rate: 1-25Hz with multiple built-in pulse and random effects
- Color Macros: Extensive built-in color presets and temperature control
Control & Programming
- Control Modes: DMX512, RDM, Art-Net (Network), Auto, Master/Slave
- DMX Channels: 10 / 17 / 136 / 139 / 153 CH modes for pixel mapping
- Display: Intuitive LCD control panel
Electrical & Physical
- Power Consumption: 1300W (AC100-240V, 50/60Hz)
- Environment: IP65 Rated (Fully waterproof for outdoor use)
- Cooling: Advanced waterproof fan cooling system
- Dimensions: 510 x 92.5 x 440 mm | Weight: 19 kg
Product Gallery
Technical Resources
Download the complete product package including user manuals, DMX charts, and technical dimensions.
Download All (ZIP)
